Dahua XVR5216AN-4KL-I3/T 16 Channel Penta-brid 4K WizSense 1U Digital Video Recorder with AI Functions and Two-Way Audio 2HDD

Description

Dahua XVR5216AN-4KL-I3/T 16 Channel Penta-brid 4K WizSense 1U Digital Video Recorder with AI Functions and Two-Way Audio 2HDD

The Dahua XVR5216AN-4KL-I3/T is a 16 channel Penta-brid WizSense digital video recorder that accepts HDCVI, AHD, TVI, CVBS and IP camera inputs all on the same unit, making it equally capable on a fresh installation or an existing analogue system being scaled up.

It records analogue channels at up to 4K at 15fps and 5MP at 25fps, and supports up to 32 IP camera inputs at up to 8MP each, all within a 128 Mbps incoming bandwidth. A 4K HDMI output ensures sharp, detailed monitoring at the display end.

AI is processed directly at the recorder level across all channels. This covers 8-channel AcuPick for fast person and vehicle search across recordings, full 16-channel SMD Plus to cut out false alarms from animals and environmental triggers, 8-channel Perimeter Protection with tripwire and intrusion detection, and 4-channel face recognition with up to 10 databases holding 20,000 images.

16-channel coaxial two-way audio allows communication to run over existing BNC cabling to compatible cameras, removing the need for separate audio wiring. Scheduled AI lets multiple AI functions be assigned per channel based on time frames, and Smart Dual Illuminator support enables compatible cameras to automatically switch between IR and white light mode when a target is detected.

Two HDD bays each support drives up to 16TB, giving a raw storage capacity of 32TB. Smart H.265+ and full-channel AI Coding keep bandwidth and storage requirements well under control throughout.

Features

• 16 channel analogue input supporting HDCVI, AHD, TVI and CVBS via auto-detection on BNC ports
• Max encoding resolution of 4K at 15fps and 5MP at 25fps on analogue channels
• Up to 32 IP camera inputs supported, up to 8MP per IP channel, max 128 Mbps incoming bandwidth
• AI Functions: 8-ch AcuPick, 4-ch Face Recognition, 8-ch Perimeter Protection with tripwire and intrusion, 1-ch EPTZ, 1-ch Privacy Protection, 16-ch SMD Plus and 16-ch AI Coding
• 16-ch coaxial two-way audio via BNC, plus 1x RCA audio in and 1x RCA audio out
• Smart H.265+, H.265, Smart H.264+ and H.264 compression with full-channel AI Coding
• Face recognition with up to 10 databases and 20,000 face images, plus 6-attribute face detection
• Scheduled AI support allowing multiple AI functions per channel based on time frames
• Smart Dual Illuminator support, automatically switching cameras between IR and white light on AI trigger
• AI Video Quality Analytics detecting brightness, colour cast, defocus and contrast issues
• 2x SATA HDD bays, each supporting up to 16TB, 32TB total raw capacity
• 1x HDMI output up to 4K (3840 x 2160) and 1x VGA output up to 1080P, simultaneous display supported
• Multi-screen display up to 16 quadrants standard, up to 36 quadrants in IP extended mode
• 1x RJ-45 Gigabit Ethernet port (10/100/1000 Mbps)
• 2x USB ports (1x USB 2.0 front, 1x USB 3.0 rear), 1x RS-485 port
• ONVIF compatible, IoT and POS functionality supported
• Mobile access via DMSS and DoLynk apps on iOS and Android
• 12VDC power supply, 1U form factor, dimensions 375 x 289.4 x 53 mm
• Operating temperature: minus 10 to plus 55 degrees C
